Facestock
A white bi-axially oriented、 polypropylene film with a print-
AZ452
receptive topcoat.
Basis Weight
Caliper
Adhesive
59 g/m?
57 um
ISO 536
IS0 534
Fasson &#174；
PP TOP WHITE -S2196-BG40WH
A special purpose permanent、 acrylic based adhesive、 designto perform at cryogenic temperatures.
L榪跩呋寢貞er
BG40 white、 a supercalendered glassine paper.
Basis Weight
Caliper
Laminate
Total Caliper
61 g/m?
54 um
ISO 536
IS0 534
134 um＋10％
ISO 534
Performance data
Initial Tack
Peel Adhesion 90°
Min. Application Temp.
Service temperature
14 N/25mm9 N/25mm
10°C
-196°C to120°C
